Mud Pumps & Parts Strong , Cost Efficient & Wide Range

ZLBW series mud pump is a horizontal, triplex, single acting reciprocation piston
pump.
It can be driven by diesel engine, electric motor or hydraulic motor. It is reliable ,agile and simple for operation. It can be controlled both at close & long-range.
It also has many other merits such as compact structure, smooth functioning , large-scale
variable rates of flow, high output pressure, longer service life of the wearing parts,
steady performance, good intensity, rigidity, plentiful standard parts, interchangeable
parts and so on.

Description

MODEL	650 LPM	850 LPM	1000 LPM	1200 LPM	1500 LPM	2000 LPM	2500 LPM	3000 LPM
Engine (KW)	54	92/75	132	154	179	194	264	264
Engine Make	Cummins	Cummins	Cummins	Cummins	Cummins	Cummins	Cummins	Cummins
Max delivery (flow)	650	850	1000	1200	1500	2000	2500	3000
Max pressure (bar)	10	10	12	12	12	15	16	16
Total weight(KG)	2150	2240	4290	4180	4500	4800	8000	10000
Dimension(mm)	24001570 1450	25001640 1450	35601800 2120	39002096 1908	38801800 2250	47502100 1950	57502600 1750	57502600 1750
Flow(lpm)/pressure(bar) on 1 st Gear	250	290	235	363	340	400-600	430-560	520-670
Flow(lpm)/pressure(bar) on2 nd Gear	380	400	380	485	550	800-1000	720-925	860-1100
Flow(lpm)/pressure(bar) on 3 rdGear	400	600	580	660	820	1200-1400	1180	1410-1810
Flow(lpm)/pressure(bar) on 4 th Gear	650	850	835	890	1110	1700	1950	2325
Flow(lpm)/pressure(bar) on 5 th Gear	NA	N/A	1000	1200	1500	2000	2500	3000
